DDevelopment & Design

Phonegap / Cordova and cross domain ssl request problem on android.

In one app I have participated, there was a use case:
  • User fill up a form.
  • User submit the form.
  • System send data via https to server and show a response.
During development there wasn’t any problem, but when we were going to release production version then some unsuspected situation occurred. I prepare the production version accordingly with standard flow for Android environment:
  • ant release
  • align
  • signing
During conduct tests on that version, every time I try to submit the form, a connection error appear. In that situation, at the first you should check whitelist in cordova settings. Every URL you want to connect to, must be explicit type in:
res/xml/cordova.xml
If whitelist looks fine, the error is most likely caused by inner implementation of Android System. The Android WebView does not allow by default self-signed SSL certs. When app is debug-signed the SSL error is ignored, but if app is release-signed connection to untrusted services is blocked.



Workaround


You have to remember that secure connection to service with self-signed certificate is risky and unrecommended. But if you know what you are doing there is some workaround of the security problem. Behavior of method
CordovaWebViewClient.onReceivedSslError
must be changed.


Thus add new class extended CordovaWebViewClient and override ‘onReceivedSslError’. I strongly suggest to implement custom onReceiveSslError as secure as possible. I know that the problem occours when app try connect to example.domain.com and in spite of self signed certificate the domain is trusted, so only for that case the SslError is ignored.

public class MyWebViewClient extends CordovaWebViewClient {

   private static final String TAG = MyWebViewClient.class.getName();
   private static final String AVAILABLE_SLL_CN
                               = "example.domain.com";

   public MyWebViewClient(DroidGap ctx) {
       super(ctx);
   }

   @Override
   public void onReceivedSslError(WebView view,
                                  SslErrorHandler handler,
                                  android.net.http.SslError error) {

       String errorSourceCName = error.getCertificate().
                                  getIssuedTo().getCName();

       if( AVAILABLE_SLL_CN.equals(errorSourceCName) ) {
           Log.i(TAG, "Detect ssl connection error: " +
                       error.toString() +
                       „ so the error is ignored”);

           handler.proceed();
           return;
       }

       super.onReceivedSslError(view, handler, error);
   }
}
Next step is forcing yours app to  use custom implementation of WebViewClient.

public class Start extends DroidGap
{
   private static final String TAG = Start.class.getName();

   @Override
   public void onCreate(Bundle savedInstanceState)
   {
       super.onCreate(savedInstanceState);
       super.setIntegerProperty("splashscreen", R.drawable.splash);
       super.init();

       MyWebViewClient myWebViewClient = new MyWebViewClient(this);
       myWebViewClient.setWebView(this.appView);

       this.appView.setWebViewClient(myWebViewClient);

       // yours code

   }
}
That is all ypu have to do if minSdk of yours app is greater or equals 8. In older version of Android there is no class
android.net.http.SslError
So in class MyCordovaWebViewClient class there are errors because compliator doesn’t see SslError class. Fortunately Android is(was) open source, so it is easy to find source of the class. There is no inpediments to ‘upgrade’ app and just add the file to project. I suggest to keep original packages. Thus after all operations the source tree looks like:

Class SslError placed in source tree.
 Now the app created in release mode can connect via https to services with self-signed SSl certificates.
DDevelopment & Design

Atom Feeds with Spring MVC

How to add feeds (Atom) to your web application with just two classes?
How about Spring MVC?

Here are my assumptions:
  • you are using Spring framework
  • you have some entity, say “News”, that you want to publish in your feeds
  • your "News" entity has creationDate, title, and shortDescription
  • you have some repository/dao, say "NewsRepository", that will return the news from your database
  • you want to write as little as possible
  • you don't want to format Atom (xml) by hand
You actually do NOT need to use Spring MVC in your application already. If you do, skip to step 3.


Step 1: add Spring MVC dependency to your application
With maven that will be:
<dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-webmvc</artifactId>
    <version>3.1.0.RELEASE</version>
</dependency>

Step 2: add Spring MVC DispatcherServlet
With web.xml that would be:
<servlet>
    <servlet-name>dispatcher</servlet-name>
    <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
    <init-param>
        <param-name>contextConfigLocation</param-name>
        <param-value>classpath:spring-mvc.xml</param-value>
    </init-param>
    <load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
    <servlet-name>dispatcher</servlet-name>
    <url-pattern>/feed</url-pattern>
</servlet-mapping>
Notice, I set the url-pattern to “/feed” which means I don't want Spring MVC to handle any other urls in my app (I'm using a different web framework for the rest of the app). I also give it a brand new contextConfigLocation, where only the mvc configuration is kept.

Remember that, when you add a DispatcherServlet to an app that already has Spring (from ContextLoaderListener for example), your context is inherited from the global one, so you should not create beans that exist there again, or include xml that defines them. Watch out for Spring context getting up twice, and refer to spring or servlet documentation to understand what's happaning.

Step 3. add ROME – a library to handle Atom format
With maven that is:
<dependency>
    <groupId>net.java.dev.rome</groupId>
    <artifactId>rome</artifactId>
    <version>1.0.0</version>
</dependency>

Step 4. write your very simple controller
@Controller
public class FeedController {
    static final String LAST_UPDATE_VIEW_KEY = "lastUpdate";
    static final String NEWS_VIEW_KEY = "news";
    private NewsRepository newsRepository;
    private String viewName;

    protected FeedController() {} //required by cglib

    public FeedController(NewsRepository newsRepository, String viewName) {
        notNull(newsRepository); hasText(viewName);
        this.newsRepository = newsRepository;
        this.viewName = viewName;
    }

    @RequestMapping(value = "/feed", method = RequestMethod.GET)
    @Transactional
    public ModelAndView feed() {
        ModelAndView modelAndView = new ModelAndView();
        modelAndView.setViewName(viewName);
        List<News> news = newsRepository.fetchPublished();
        modelAndView.addObject(NEWS_VIEW_KEY, news);
        modelAndView.addObject(LAST_UPDATE_VIEW_KEY, getCreationDateOfTheLast(news));
        return modelAndView;
    }

    private Date getCreationDateOfTheLast(List<News> news) {
        if(news.size() > 0) {
            return news.get(0).getCreationDate();
        }
        return new Date(0);
    }
}
And here's a test for it, in case you want to copy&paste (who doesn't?):
@RunWith(MockitoJUnitRunner.class)
public class FeedControllerShould {
    @Mock private NewsRepository newsRepository;
    private Date FORMER_ENTRY_CREATION_DATE = new Date(1);
    private Date LATTER_ENTRY_CREATION_DATE = new Date(2);
    private ArrayList<News> newsList;
    private FeedController feedController;

    @Before
    public void prepareNewsList() {
        News news1 = new News().title("title1").creationDate(FORMER_ENTRY_CREATION_DATE);
        News news2 = new News().title("title2").creationDate(LATTER_ENTRY_CREATION_DATE);
        newsList = newArrayList(news2, news1);
    }

    @Before
    public void prepareFeedController() {
        feedController = new FeedController(newsRepository, "viewName");
    }

    @Test
    public void returnViewWithNews() {
        //given
        given(newsRepository.fetchPublished()).willReturn(newsList);

        //when
        ModelAndView modelAndView = feedController.feed();

        //then
        assertThat(modelAndView.getModel())
                .includes(entry(FeedController.NEWS_VIEW_KEY, newsList));
    }

    @Test
    public void returnViewWithLastUpdateTime() {
        //given
        given(newsRepository.fetchPublished()).willReturn(newsList);

        //when
        ModelAndView modelAndView = feedController.feed();

        //then
        assertThat(modelAndView.getModel())
                .includes(entry(FeedController.LAST_UPDATE_VIEW_KEY, LATTER_ENTRY_CREATION_DATE));
    }

    @Test
    public void returnTheBeginningOfTimeAsLastUpdateInViewWhenListIsEmpty() {
        //given
        given(newsRepository.fetchPublished()).willReturn(new ArrayList<News>());

        //when
        ModelAndView modelAndView = feedController.feed();

        //then
        assertThat(modelAndView.getModel())
                .includes(entry(FeedController.LAST_UPDATE_VIEW_KEY, new Date(0)));
    }
}
Notice: here, I'm using fest-assert and mockito. The dependencies are:
<dependency>
 <groupId>org.easytesting</groupId>
 <artifactId>fest-assert</artifactId>
 <version>1.4</version>
 <scope>test</scope>
</dependency>
<dependency>
 <groupId>org.mockito</groupId>
 <artifactId>mockito-all</artifactId>
 <version>1.8.5</version>
 <scope>test</scope>
</dependency>

Step 5. write your very simple view
Here's where all the magic formatting happens. Be sure to take a look at all the methods of Entry class, as there is quite a lot you may want to use/fill.
import org.springframework.web.servlet.view.feed.AbstractAtomFeedView;
[...]

public class AtomFeedView extends AbstractAtomFeedView {
    private String feedId = "tag:yourFantastiSiteName";
    private String title = "yourFantastiSiteName: news";
    private String newsAbsoluteUrl = "http://yourfanstasticsiteUrl.com/news/";

    @Override
    protected void buildFeedMetadata(Map<String, Object> model, Feed feed, HttpServletRequest request) {
        feed.setId(feedId);
        feed.setTitle(title);
        setUpdatedIfNeeded(model, feed);
    }

    private void setUpdatedIfNeeded(Map<String, Object> model, Feed feed) {
        @SuppressWarnings("unchecked")
        Date lastUpdate = (Date)model.get(FeedController.LAST_UPDATE_VIEW_KEY);
        if (feed.getUpdated() == null || lastUpdate != null || lastUpdate.compareTo(feed.getUpdated()) > 0) {
            feed.setUpdated(lastUpdate);
        }
    }

    @Override
    protected List<Entry> buildFeedEntries(Map<String, Object> model, HttpServletRequest request, HttpServletResponse response) throws Exception {
        @SuppressWarnings("unchecked")
        List<News> newsList = (List<News>)model.get(FeedController.NEWS_VIEW_KEY);
        List<Entry> entries = new ArrayList<Entry>();
        for (News news : newsList) {
            addEntry(entries, news);
        }
        return entries;
    }

    private void addEntry(List<Entry> entries, News news) {
        Entry entry = new Entry();
        entry.setId(feedId + ", " + news.getId());
        entry.setTitle(news.getTitle());
        entry.setUpdated(news.getCreationDate());
        entry = setSummary(news, entry);
        entry = setLink(news, entry);
        entries.add(entry);
    }

    private Entry setSummary(News news, Entry entry) {
        Content summary = new Content();
        summary.setValue(news.getShortDescription());
        entry.setSummary(summary);
        return entry;
    }

    private Entry setLink(News news, Entry entry) {
        Link link = new Link();
        link.setType("text/html");
        link.setHref(newsAbsoluteUrl + news.getId()); //because I have a different controller to show news at http://yourfanstasticsiteUrl.com/news/ID
        entry.setAlternateLinks(newArrayList(link));
        return entry;
    }

}

Step 6. add your classes to your Spring context
I'm using xml approach. because I'm old and I love xml. No, seriously, I use xml because I may want to declare FeedController a few times with different views (RSS 1.0, RSS 2.0, etc.).

So this is the forementioned spring-mvc.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd">

    <bean class="org.springframework.web.servlet.view.ContentNegotiatingViewResolver">
        <property name="mediaTypes">
            <map>
                <entry key="atom" value="application/atom+xml"/>
                <entry key="html" value="text/html"/>
            </map>
        </property>
        <property name="viewResolvers">
            <list>
                <bean class="org.springframework.web.servlet.view.BeanNameViewResolver"/>
            </list>
        </property>
    </bean>

    <bean class="eu.margiel.pages.confitura.feed.FeedController">
        <constructor-arg index="0" ref="newsRepository"/>
        <constructor-arg index="1" value="atomFeedView"/>
    </bean>

    <bean id="atomFeedView" class="eu.margiel.pages.confitura.feed.AtomFeedView"/>
</beans>

And you are done.

I've been asked a few times before to put all the working code in some public repo, so this time it's the other way around. I've describe things that I had already published, and you can grab the commit from the bitbucket.

Hope that helps.
